| Technical Specification | Unit | MJ183 | MJ184 |
| Min. sawing length | mm | 200 | 200 |
| Sawing thickness | mm | 10-70 | 10-120 |
| Main saw blade dia. | mm | ?305-?355 | ?355-?455 |
| Main spindle dia. | mm | ?50.8 | ?50.8 |
| Main spindle speed | r/min | 4200 | 2930 |
| Main motor power | Kw | 7.5 | 11 |
| Feeding motor power | Kw | 1.5 | 1.5 |
| Feeding speed | m/min | 10-26 | 10-26 |
| Overall dimensions | mm | 1856×1068×1314 | 2100×1716×1500 |
| Net.weight |
kg |
1100 |
1800 |
